18" Riser Post Roof Anchor (ANSI)
18" Riser Post Roof Anchor (ANSI)
KStrong® Riser Post Roof Anchor (ANSI)
Product Code: UFA55207SW(18)
The KStrong® Anchor is expertly designed for secure installation on metal I-beams, facilitating the setup of horizontal lifelines. It features an adjustable base opening to accommodate various beam sections, ensuring versatility and ease of use. Installation is straightforward and quick, utilizing the included M12 nut and bolt system. The post comes pre-fitted with a D-ring for immediate connections, providing a reliable anchorage point. Constructed from high-strength alloy steel and finished with a black ED coating, this anchor guarantees durability and long-lasting performance. It meets or exceeds ANSI/ASSE Z359.18-2017 Type A standards.
Feature | Specification |
|---|---|
| Design | Fixed on metal I-beams for horizontal lifeline installation; adjustable base opening; easy installation with nut & bolt (M12); pre-installed D-ring for connections |
| Length (L) | 18 in. (457.2 mm) |
| Compatible with Minimum Flange Width | 5.91 in. (150 mm) |
| Compatible with Maximum Flange Width | 8.66 in. (220 mm) |
| Material | Alloy Steel |
| Finish | ED Coated Black |
| System Strength | 23 kN |
| Weight | 21.05 lbs. ± 0.44 lbs. (9.55 kgs ± 0.20 kgs) |
| Relevant Standards | Meets or Exceeds ANSI/ASSE Z359.18-2017 Type A |
