Aluminum Bulb Type .67” Opening Carabiner (ANSI)
Aluminum Bulb Type .67” Opening Carabiner (ANSI)
KStrong® Aluminum Bulb Type .67” Opening Carabiner (ANSI)
Product Code: UFC401400
The KStrong® Forged Oval Carabiner is a high-strength, lightweight carabiner designed for secure connections in various industrial applications. Featuring a 0.67” (17mm) gate opening, this carabiner is made from high-strength aluminum alloy. It has a self-closing and automatic key locking (anti-snag) mechanism for enhanced safety and ease of use. The key locking is secured by a quarter turn nut. With a minimum breaking strength of 5000 lbs., this carabiner meets or exceeds ANSI Z359.12-2009 & CSA Z259.12 standards, ensuring maximum safety and reliability.
Feature | Specification |
|---|---|
| Product Name | KStrong® Forged Oval Carabiner with 0.67” Gate Opening (ANSI) |
| Design | Gate opening 0.67” (17mm), self-closing and automatic key locking (anti-snag) mechanism |
| Material | High strength Aluminum Alloy |
| Minimum Breaking Strength | 5000 lbs. (2268kg) |
| Gate Face Strength | 3600 lbs. (1633kg) |
| Gate Side Strength | 3600 lbs. (1633kg) |
| Weight | 0.22 lbs. ± 0.02 lbs. (100 gm. ± 10 gm) |
| Relevant Standard | Meets or Exceeds ANSI Z359.12-2009 & CSA Z259.12 |
